WiiM MOD A80

WiiM CI MOD A80 – Pro-grade power in a compact rack-ready form

A refined stereo amplifier built with Origin Acoustics, designed for high-performance custom installations. It pairs a premium ESS ES9038Q2M DAC with the efficient TI TPA3255 Class-D module to deliver clean, detailed Hi-Res playback up to 192 kHz/24-bit. Its rack-friendly chassis and robust build make it a solid choice for both residential and commercial setups.

You get broad connectivity for modern systems: HDMI ARC for TVs, optical and RCA for classic sources, USB for local files, plus dual-band Wi-Fi, Ethernet, Chromecast and Bluetooth 5.3 for wireless streaming. It also supports multiroom audio with Amazon Echo, Google Home and the full WiiM ecosystem, handling popular services like Spotify, TIDAL Connect, Alexa Cast and more. A dedicated subwoofer output lets you build a powerful 2.1 system with ease.

Technical Specifications – WiiM CI MOD A80

Brand: WiiM
Series: Professional CI Series
Model: CI MOD A80
Type: Stereo amplifier with network streamer

Power Output (8 Ω): 60 W per channel

Inputs:
• HDMI ARC
• RCA L/R
• USB
• Optical
• Bluetooth 5.3

Memory: 512 MB DRAM / 512 MB Flash
DAC: ESS ES9038Q2M
Processor: Quad-Core ARM Cortex-A53

Connectivity:
• Bluetooth
• Chromecast
• DLNA
• Ethernet
• Wi-Fi

SNR: 98 dB
Amplifier Class: D
THD+N: –92 dB (0.002%)
Max Sample Rate: 192 kHz / 24-bit

Subwoofer Output: RCA mono
Amplifier Module: TI TPA3255
Zones: 1

Multiroom Support:
Amazon Echo, Google Home, WiiM ecosystem

Music Services:
Alexa Cast, Amazon Music, Deezer, Napster, Pandora, Qobuz, SoundCloud, SoundMachine, Spotify, TIDAL, TIDAL Connect, TuneIn, iHeartRadio, vTuner

Supported Formats:
AAC, AIFF, ALAC, APE, FLAC, MP3, OGG, WAV, WMA

Features: Rack-mount ready
Pack Unit: 1 pc
Color: Dark grey
Warranty: 2 years
